15
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Compressor
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD
ZHUHAI LANDA COMPRESSOR
CO., LTD
Compressor Model QXD-B160T130C QXD-A121L130B
Compressor Oil 5GSD-TB or equivalent 5GSD-TB or equivalent
Compressor Type Rotary Rotary
L.R.A. A 19 12
Compressor RLA A 3.2 2.7
Compressor Power Input W 726 586
Overload Protector HPA-018 HPA-012
Evaporator
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ146X108.5 Φ146X108.5
Fan Motor Speed(H/M/L) rpm 1300/1235/1155 1225/1140/1025
Output of Fan Motor W 45 45
Fan Motor RLA A 0.41 0.5
Fan Motor Capacitor μF 4.5 4
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 2-1.3 2-1.3
Coil Length (LXDXW) mm 380X25.4X228.6 380X25.4X228.6
Swing Motor Model / /
Output of Swing Motor W / /
Condenser
Fan Type Centrifugal Centrifugal
Fan Diameter mm Φ185 Φ185
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ5 Φ5
Rows-n Gap mm 2-1.5+1-1.4 2-1.5,1-1.4
Coil Length (LXDXW) mm 383X266.7X22.8+334X266.7X11.4 383X266.7X22.8+334X266.7X11.4
Fan Motor Speed rpm 1300/1235/1155 1225/1140/1025
Output of Fan Motor W 45 45
Fan Motor RLA A 0.41 0.5
Fan Motor Capacitor μF 4.5 4
