23
Technical Information
Service Manual
4. Refrigerant System Diagram
OUTDOOR COILS
HOT DISCHARGED AI
R
COMPRESSOR
CENTRIFUGAL FAN
CENTRIFUGAL FAN
CAPILLARY
REFRIGERANT FLOW DIRECTION
COOLED AIR
INDOOR COILS
