PARTS INCLUDED
Window Exhaust Adapter A
Window Locking Bracket
Screw (8)
Exhaust Hose
Foam Seal B (2)
Foam Seal A
Window Exhaust Adapter C
Window Slider Bracket (4)
Rain Deflector Assembly
Protective Screen
Adjustable Window Slider (3)
Bolt ( )
4
Washer ( )
4
Nut ( )
4
Split-Ring Washer (
4)
Drain hose Hose Clamp Hose clip (2) Rubber plug
Battery (2)
(AAA.1.5V)
-4-
INCLUDE
Window Exhaust Adapter B
Screw ( 2 )
Optional
SUGGESTED TOOLS FOR WINDOW PANEL
INSTALLATION
1. Screw driver (medium size Phillips) 2. Tape measure or ruler 3. Knife or scissors
4. Saw (In the event that the window panel needs to be cut down in size because the window is too narrow for
direct installation.)
ManualRemove control
hoo k (2)
Power cord
To Next Page
