Installof drainage hose(as shown in following figure):
Note:Drainage hose must be installed before using other wise block of drain may occur and affects
normal run of unit.
1. Remove drain cap from drain port.
A.
B.
A
B
-7-
INSTALLATION OF DRAINAGE HOSE
A .Rubber plug
B. Drain port
C. Drain hose
D.
E.
Drain hose clamp
Drain hose clips
3. Attach one end of the drain hose to the drain port with the clip.
4. Insert the rubber plug into the other end of the drain hose and secure with clip.
2. Attach the drain hose clamp to the back panel of the air conditioner near the
drain port with the screw.
Drain port
Drain cap
A
B
C
E
D
A. Drain port
B
.Drain hose clamp
A
B
To Next Page
