Installation and Maintenance
No. Description Qty No. Description Qty
1 Condenser Assy 1 18 Foam 4
2 Capillary Sub-assy 1 19 Sponge (sealing strip) 1
3 Compressor and Fittings 1 20 Chassis Assy 1
4 Compressor Gasket 4 21 Sponge 3
5 4-Way Valve Assy 1 22 Motor base Assy 3
6 Water bae (4-way valve) 1 23 Electric Box Assy 1
7 Water bae (xing pipe) 1 24 Main Board 1
2 Centrifugal fan (inside) 1 25 Capacitor CBB61S 2
9 Centrifugal fan blade 1 26 Capacitor CBB65 1
10 Fan Motor 1 27 Temperature Sensor 1
11 Sensor Insert 2 28 Electric Box Cover 1
12 Evaporator Assy 1 29 Centrifugal fan (outside) 1
13 Foam (inner side) 1 30 Centrifugal fan blade 2
14 Connecting Cable 1 31 Fan Motor 1
15 Remote Controller 1 32 Foam (outside) 1
16 mounting plat Sub-Assy 2 33 Cabinet 1
17 Bolt 4
Some models may not contain some parts,
please refer to the actual product.
