3
Technical Information
Model GRH085DB-K6NA1A GRH085DB-K6NA1A
Product Code CU050001300 CU050001301
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling Capacity W 2600 2600
Heating Capacity W 2400 2400
Cooling Power Input W 1160 1160
Heating Power Input W 1000 1000
Cooling Current Input A / /
Heating Current Input A / /
Rated Input W 1600 1600
Rated Current A / /
EER W/W / /
COP W/W / /
Air Flow Volume m
3
/h 330/250/200 330/250/200
Dehumidifying Volume L/h 1 1
Application Area m
2
10-17 10-17
Set Temperature Range
o
C 16~30 16~30
Cooling Operation Ambient Temperature Range
o
C 18~46 18~46
Heating Operation Ambient Temperature Range
o
C -5~24 -5~24
Indoor Unit
Model GRH085DB-K6NA1A/I GRH085DB-K6NA1A/I
Product Code CU050N01300 CU050N01301
Swing Motor Model
/ /
Swing Motor Power Output W
/ /
Fuse Current A 3.15 3.15
Dimension (WXHXD) mm 610X485X49 610X485X49
Dimension of Carton Box (LXWXH) mm 668X547X109 /
Dimension of Package (LXWXH) mm 678X550X112 /
Net Weight kg 2.7 2.7
Gross Weight kg 4 /
Fan Type Centrifugal Centrifugal
Fan Diameter Length mm Φ150x177.5 Φ150x177.5
Cooling Speed r/min 1680/1320/1100 1680/1320/1100
Heating Speed r/min 1680/1320/1100 1680/1320/1100
Fan Motor Power Output W 38 38
Fan Motor RLA A 0.62 0.62
Fan Motor Capacitor μF 3.5 3.5
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ7 Φ7
Evaporator Row-n Gap mm 3-1.4 3-1.4
Evaporator Coil Length mm 666×38.1×152.4 666×38.1×152.4
2. Specications
