4
Technical Information
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Unit
Model GRH085DB-K6NA1A/O GRH085DB-K6NA1A/O
Product Code CU050W01300 CU050W01301
Compressor Trademark HIGHLY HIGHLY
Compressor Manufacturer
SHANGHAI HIGHLY
ELECTRICAL APPLIANCES CO.,LTD
SHANGHAI HIGHLY
ELECTRICAL APPLIANCES CO.,LTD
Compressor Model GDD102SV-A3D GDD102SV-A3D
Compressor Oil ACS-68R ACS-68R
Compressor Type Rotary Rotary
Compressor Locked Rotor Amp A 18.9 18.9
Compressor Rated Load Amp A 3.85 3.85
Compressor Power Input W 828 828
Compressor Overload Protector Internal Internal
Fan Type Centrifugal Centrifugal
Fan Diameter mm Φ150 Φ150
Fan Motor Speed rpm 1400 1400
Fan Motor Power Output W 42 42
Fan Motor RLA A 0.38 0.38
Fan Motor Capacitor μF 3.5 3.5
Air Flow Volume m
3
/h 600 600
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ7 Φ7
Condenser Rows-n Gap mm 3-1.4 3-1.4
Condenser Coil Length mm 552×38.1×228.6 552×38.1×228.6
Permissible Excessive Operating
Pressure for the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating
Pressure for the Suction Side
MPa 2.5 2.5
Maximum Allowable Pressure MPa 4.3 4.3
Throttling Method Capillary Capillary
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Refrigerant R32 R32
Refrigerant Charge kg 0.47 0.47
Dimension (WXHXD) mm 1077X720X283 1077X720X283
Dimension of Carton Box (LXWXH) mm 1146X783X330 1146X783X405
Dimension of Package (LXWXH) mm 1149X786X353 1149X786X435
Net Weight kg 35 35
Gross Weight kg 44 /
