Technical Information
Service Manual
GWC12ATCXB-D3DNA1C/O GWH12ATCXB-D3DNA1C/O GWC09ATCXB-D3DNA1A/O GWH09ATCXB-D3DNA1A/O
No. Name No. Name
1 Earthing wire terminal 7 Fan motor terminal
2 Live wire terminal 8 Electron expansion valve terminal
3 Neutral wire terminal 9 Compressor overload terminal
4 Communication terminal 10 Temperature sensor terminal
5 4-way valve terminal 11 E store terminal
6 Electric heating terminal of chassis 12 Compressor terminal
4LIV12HP230V1AO 4LIV09HP230V1AO
