Gree GWC12ATCXB-A3DNA1C/I User Manual

7
Technical Information
Service Manual
Model
GWH12ATCXB-A3DNA1C
GWH12ATCXB-A3DNA3C
GWC12ATCXB-A3DNA1C
Product Code
CB574001400
CB590000400
CB574001200
Power
Supply
Rated Voltage V~ 115 115
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity Btu/h 12000 12000
Heating Capacity Btu/h 12000 /
Cooling Power Input W 1380 1380
Heating Power Input W 1004 /
Cooling Current A 15 15
Heating Current A 10.9 /
Rated Input W 1650 1500
Rated Current A 17.9 16.3
EER (Btu/h)/W 8.7 8.7
COP (Btu/h)/W 11.95 /
SEER 17.5(SEER) 17.5(SEER2) 17.5(SEER) 17.5(SEER2)
HSPF 10(HSPF) 8.5(HSPF2) /
Air Flow Volume CFM 424/353/324/277/247/224/182 424/353/324/277/247/224/182
Dehumidifying Volume Pint/d 2.96 2.96
Application Area yd
2
19-29 19-29
Indoor Unit
Indoor Unit Model
GWH12ATCXB-A3DNA1C/I
GWH12ATCXB-A3DNA3C/I
GWC12ATCXB-A3DNA1C/I
Product Code of Indoor Unit
CB574N01400
CB590N00400
CB574N01200
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Ф94X630 Ф94X630
Cooling Speed r/min 1550/1200/1120/1050/980/920/750/500 1550/1200/1120/1050/980/920/750/500
Heating Speed r/min 1450/1200/1140/1080/1020/960/900/- /
Fan Motor Power Output W 15 15
Fan Motor RLA A 0.40 0.40
Fan Motor Capacitor μF / /
Heater Power Input W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф5 Ф5
Evaporator Row-n Gap mm 2-1.3 2-1.3
Evaporator Coil Length (LXDXW) mm 634X22.8X266.7 634X22.8X266.7
Swing Motor Model MP24HF MP24HF
Swing Motor Power Output W 1.5 1.5
Fuse Current A 3.15 3.15
Sound Pressure Level dB (A)
Cooling:47/39/38/35/33/32/27
Heating:44/39/37/36/34/32/30
47/39/38/35/33/32/27
Sound Power Level dB (A)
Cooling:57/49/48/45/43/42/37
Heating:54/49/47/46/44/42/40
57/49/48/45/43/42/37
Dimension (WXHXD) inch 32 7/8X10 53/64X7 7/8 32 7/8X10 53/64X7 7/8
Package Carton Dimension
(LXWXH)
inch 35 3/64X12 61/64X10 15/64 35 3/64X12 61/64X10 15/64
Package Dimension (LXWXH) inch 35 15/64X13 37/64X10 43/64 35 15/64X13 37/64X10 43/64
Net Weight Ib 19.8 19.8
Gross Weight Ib 24.3 24.3

Gree GWC12ATCXB-A3DNA1C/I Specifications

General

Brand	Gree
Model	GWC12ATCXB-A3DNA1C/I
Category	Heat Pump
Language	English
