Technical Information
Service Manual
Outdoor
Unit
Outdoor Unit Model GWC12ATCXB-D3DNA1C/O GWH12ATCXB-D3DNA1C/O
Product Code of Outdoor Unit CB574W01300 CB574W01500
Compressor Manufacturer
ZHUHAI LANDA COMPRESSOR
CO.,LTD
ZHUHAI LANDA COMPRESSOR
CO.,LTD
Compressor Model FTz-AN108ACBD FTz-AN108ACBD
Compressor Oil FW68DA or equivalent FW68DA or equivalent
Compressor Type Rotary Rotary
Compressor LRA. A / /
Compressor RLA A 7.30 7.30
Compressor Power Input W 857 857
Compressor Overload Protector / /
Fan Type Axial-ow Axial-ow
Fan Diameter mm 400 400
Fan Motor Speed rpm 900 900
Fan Motor Power Output W 30 30
Fan Motor RLA A 0.60 0.60
Fan Motor Capacitor μF / /
Outdoor Unit Air Flow Volume CFM 1148 1148
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Ф5 Ф7
Condenser Rows-n Gap mm 1-1.3 1-1.2
Condenser Coil Length (LXDXW) mm 675X11.4X514.4 677X19.05X528
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5 2.5
Maximum Allowable Pressure MPa 4.3 4.3
Set Temperature Range
º
F 61~86 61~86
Cooling Operation Ambient Temperature Range
º
F 0~115 0~115
Heating Operation Ambient Temperature Range
º
F / -4~75
Throttling Method Capillary Capillary
Defrosting Method / Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Sound Pressure Level dB (A) 51 52
Sound Power Level dB (A) 61 62
Dimension (WXHXD) inch 28 13/16X21 27/32X12 63/64 28 13/16X21 27/32X12 63/64
Dimension of Carton Box (LXWXH) inch 31 9/64X14 11/16X23 15/64 31 9/64X14 11/16X23 15/64
Dimension of Package(LXWXH) inch 31 17/64X14 51/64X24 7/32 31 17/64X14 51/64X24 7/32
Net Weight lb 54.022 57.33
Gross Weight lb 59.535 62.842
Refrigerant R410A R410A
Refrigerant Charge oz 19.4 27.5
Connection
Pipe
Length ft 24.6 24.6
Gas Additional Charge oz/ft 0.16 0.22
Outer Diameter Liquid Pipe inch 1/4 1/4
Outer Diameter Gas Pipe inch 3/8 3/8
Max. Height Distance ft 32.8 32.8
Max. Length Distance ft 65.6 65.6
Note: The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
