Technical Information
Service Manual
Parameter Unit Value
Model 7.GWH09QB-K3DNB2G
6.GWH12QC-K3DNB2G
7.GWH12QC-K3DNC4G
Product Code 7.CB432002204
6.CB432002103
7.CB444001302
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity(Min~Max) W 2600(450~3230) 3500(600~3960)
Heating Capacity(Min~Max) W 2800(450~4100) 3670(600~5130)
Cooling Power Input(Min~Max) W 805(200~1420) 1084(220~1550)
Heating Power Input(Min~Max) W 755(200~1550) 989(220~1650)
Cooling Current Input A 3.7 5.2
Heating Current Input A 3.4 5.0
Rated Input W 1550 1650
Rated Current A 6.3 6.9
Air Flow Volume(SH/H/M//L/SL) m
3
/h 560/490/430/330/- 660/540/460/330/-
Dehumidifying Volume L/h 0.8 1.4
EER W/W 3.23 3.23
COP W/W 3.71 3.71
SEER W/W 6.1 6.1
SCOP W/W / /
Application Area m
2
12-18 16-24
Indoor
Unit
Indoor Unit Model 7.GWH09QB-K3DNB2G/I
6.GWH12QC-K3DNB2G/I
7.GWH12QC-K3DNC4G/I
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Ф98X580 Ф98X633.5
Cooling Speed(SH/H/M//L/SL)
r/
min
1300/1200/1050/800/- 1350/1200/1050/850/-
Heating Speed(SH/H/M//L/SL)
r/
min
1300/1200/1050/900/- 1300/1150/1000/900/-
Fan Motor Power Output W 20 20
Fan Motor RLA A 0.22 0.31
Fan Motor Capacitor μF 1 1.5
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ5 Φ5
Evaporator Row-n Gap mm 2-1.4 2-1.4
Evaporator Coil Length (LXDXW) mm 584X22.8X266.7 635X22.8X306.3
Swing Motor Model MP24AA MP24BA
Swing Motor Power Output W 1.5 1.5
Fuse Current A 3.15 3.15
Sound Pressure Level(SH/H/M//L/
SL)
dB
(A)
39/36/32/26/- 39/33/26/-/-
Sound Power Level(SH/H/M//L/SL)
dB
(A)
49/46/42/36/- 49/43/36/-/-
Dimension (WXHXD) mm 790X275X200 845X289X209
Dimension of Carton Box (LXWXH) mm 863X268X352 918X278X364
Dimension of Package(LXWXH) mm 866X271X367 921X281X379
Net Weight kg 9 10
Gross Weight kg 11 12
