Gree GWH09QB-K3DNC2G

89
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
GWH09QB-K3DNB4G/I(WIFI) GWH09QB-K3DNC2G/I(WIFI)
Product Code CB434N02304 CB439N00402
1 Front Panel Assy 00000200040 00000200040 1
2 Display Board 30565260 30565281 1
3 Front Case Assy 00000200040 00000200040 1
4 Helicoid Tongue 26112508 26112508 1
5 Left Axile Bush 10512037 10512037 1
6 Rear Case assy 20162010 20162010 1
7 Drainage Hose 0523001408 0523001408 1
8 Ring of Bearing 26152022 26152022 1
9 Evaporator Support 24212180 24212180 1
10 Cold Plasma Generator 1114001603 1114001603 1
11 Evaporator Assy 01002000044 01002000044 1
12 Wall Mounting Frame 01252043 01252043 1
13 Cross Flow Fan 10352059 10352059 1
14 Fan Motor 150120874 150120874 1
15 Connecting pipe clamp 2611216401 2611216401 1
16 Rubber Plug (Water Tray) 76712012 76712012 1
17 Stepping Motor 1521212901 1521212901 1
18 Crank 73012005 73012005 1
19 Electric Box Assy 10000203105 10000203603 1
20 Axile Bush 10542036 10542036 1
21 Terminal Board 42011233 42011233 1
22 Jumper 4202021904 4202021904 1
23 Main Board 30145096 30145096 1
24 Electric Box Cover Sub-Assy 0140206501 0140206501 1
25 Shield Cover of Electric Box Cover 01592150 01592150 1
26 Electric Box Cover 20112207 20112207 1
27 Power Cord / / /
28 Connecting Cable 4002052317 4002052317 0
29 Remote Controller 30510474 30510468 1
30 Capacitor CBB61S 33010747 33010747 1
31 Detecting plate(WIFI ) 30110154 30110154 1
