6
Technical Information
Service Manual
3. Outline Dimension Diagram
3.1 Indoor Unit
Unit:mm
Model W H D
09K/12K 996 301 225
09/12K
WD
H
117 685 194
140
190
38
Φ55
Φ55
38
