Gree GWH18KG-K3DNA5G - 11.2 Removal Procedure of Outdoor Unit

81
Installation and Maintenance
Service Manual
Twist off the screws used for fixing the handle and
v
alve cover ,
pull the handle and v
alve cover up
ward to remove it.
b
a
a
1. Remove top panel
Remove
handle
valve
top panel
top panel
the 3 screws connecting the top
panel with the front panel and the right side
plate, and then remove the top panel.
2. Remove grille , panel and rear grill
Remove the 2 screws connecting the grille
and the panel, and then remove the grille.
Steps Procedure
11.2 Removal Procedure of Outdoor Unit
Warning: Be sure to wait for a minimum of 20 minutes after
turning off all power supplies and discharge the refrigerant
completely before removal.
GWH18KG-K3DNA6G/O
