Typical Installation
CURB INSTALLATION HOLES
(REFERENCE NOTES)
HOOD INSTALLATION HOLES
(REFERENCE NOTES)
HOOD INSTALLTION NOTES:
HOOD INSTALLATION HOLES MAY ONLY BE PRESENT AT BASE CORNERS FROM FACTORY.
INSTALLATION FASTENERS MAY VARY DUE TO PROJECT LOCATION, LOCAL STRUCTURAL
CODES, OR ENVIRONMENTAL CONDITIONS (I.E. HIGH WIND).
CONSULT PROJECT/SITE ENGINEER ON INSTALLATION HARDWARE INFORMATION
INCLUDING QUANTITIES, MAXIMUM SPACING, AND HARDWARE TYPE.
CURB INSTALLATION NOTES:
CURB ANCHOR HOLES PROVIDED BY MANUFACTURER, HOWEVER ADDITIONAL ANCHORS
MAY BE REQUIRED DEPENDING ON SITE LOCATION AND LOCAL CODES.
CONSULT PROJECT/SITE ENGINEER FOR PROJECT-SPECIFIC ANCHOR CALCULATIONS.
FOR HIGH-WIND RATED HOOD, FOLLOW HIGH-WIND INSTRUCTIONS STARTING ON PAGE 6.
