EK22GL Battery-powered, High-speed Crimping Tool
Greenlee / A Textron Company 18 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
Parts List (cont’d)
Key Part No. Description Qty
500 1593.1 Relief valve assembly (includes items 120–130)
120 500 5860.6 Washer ......................................................................................... 1
121* 500 4134.7 O-ring............................................................................................ 1
122* 500 5862.2 Seal .............................................................................................. 1
123 500 5363.0 Valve seat ..................................................................................... 1
124 500 5864.9 Plunger ......................................................................................... 1
125* 500 5869.0 O-ring............................................................................................ 1
126 500 5871.1 Pressure relief .............................................................................. 1
127 500 5875.4 Support ring .................................................................................. 1
128* 500 5876.2 Retaining ring ............................................................................... 1
129 500 5877.0 Needle valve ................................................................................. 1
130 500 5894.0 Spring ........................................................................................... 1
500 1347.5 Electrical assembly (includes items 140–144)
140 500 4126.6 Switch ........................................................................................... 1
141 500 4127.4 Battery contacts ............................................................................ 1
142 500 7151.3 Circuit board, programmed ........................................................... 1
143 500 5899.1 Wire (not shown) .......................................................................... 1
144 500 5900.9 Wire (not shown) .......................................................................... 1
500 1348.3 Piston pump assembly (includes items 150–156)
150 500 5891.6 Pump piston.................................................................................. 1
151 501 0365.2 Screw plug .................................................................................... 1
152 501 0370.9 Pump piston.................................................................................. 1
153* 501 0369.5 Washer ......................................................................................... 1
154* 501 0366.0 Sealing washer ............................................................................. 1
155 501 0367.9 Spring ........................................................................................... 1
156 501 0368.7 Valve stem .................................................................................... 1
500 4292.0 W-type die adapter
500 4625.0 W-type die release kit (includes items 23, 33, 34, 36)
500 4626.8 Die release kit (includes items 22, 23, 30–32)
* 500 1407.2 Seal kit (includes items marked with an asterisk)
** 918 7141.7 Capacitor assembly (includes items marked with double asterisks)
† 501 1892.7 Release lever assembly (includes items marked with a †)
500 5954.8 Case with inserts
500 4270.0 Decal, connector compatibility
500 2999.1 12 V battery NiCd
500 3046.9 12 V charger 110 VAC
500 3047.7 12 V charger 220 VAC
500 3048.5 12 V charger 12 VDC
