Disassembly/Assembly
assembly
Refer to Tools & Workspace from Disassembly Section
Installing the FRONT GRILLE:
1. Gently put the Front Grille in place on the front of the unit, being careful not to
damage the Ionization Needle at the top center of the front of the unit.
2. Insert the four Front Grille Screws one at a time until they are in place, but not
tight. After all four Front Grille Screws are in place, tighten them carefully.
Installing the PCO CELL:
1. Position the PCO Cell inside the unit so that the two tabs are on the bottom
(and interior side) of the PCO Cell. Ensure the holes in the two tabs t over the
two Screw Posts. Screw the Thumb Nuts onto the Screw Posts until they are snug.
2. Align the PCO Cell Power Connector to the PCO Cell Power Connector Outlet and
insert gently until the tabs at the top and bottom of the PCO Cell Power Connector
snap into place, holding it in the PCO Cell Power Connector Outlet.
Installing the PURIFICATION PLATE:
1. Holding the Purication Plate by the ceramic, slowly insert it into the Purication Plate
Slot, ensuring that the Purication Plate is sliding into the grooves on either side.
NOTE: About halfway in, the Purication Plate Connectors are parted. Continue
sliding the Purication Plate into the Purication Plate Slot until there is approximately
one inch of the Purication Plate remaining outside of the Purication Plate Slot and
signicant resistance is met. Be careful not to force the Purication Plate further into
the Purication Plate Slot as this could seriously damage your unit.
Installing the FILTER ASSEMBLY:
1. Hold the Filter Assembly with the larger at side (where the honeycomb layer of
the lter is visible) facing the interior of the unit. A sticker reading, “Caution:
Reinstall Filter After Cleaning,” is located on the opposite side of the Filter
Assembly. This sticker should be visible when you install the Filter Assembly.
2. Insert the bottom of the Filter Assembly into the tabs on the rear of the unit and
then seat the Filter Assembly on the rear of the unit. (NOTE: If the user fails to
insert the Filter Assembly into the tabs appropriately, disassembling the unit in
the future could be extremely difcult.)
3. Screw the two Brass Thumbscrews into their holes at the top corners of the
Filter Assembly.
Installing the Rear Cover:
1. Place the tab at the top of the Rear Cover into the hole at the top of the Filter
Assembly then lay the Rear Cover at against the rear of the unit until the tabs on
the sides of the Rear Cover click into place on the unit.
2. Carefully insert the Rear Cover Screw into its hole on the Rear Cover (above the
Power Cord Port) and tighten.
Installing the POWER CORD:
1. Insert the Power Adapter Plug into the rear of the unit.
2. Ensure the Power Cord is properly connected to the Power Adapter.
3. Insert the Power Plug into a wall outlet.
Turning the unit on:
1. Press the power button.
2. The unit will be set to Normal Mode once again. Ensure that the unit’s settings are
adjusted to suit the environment (see “Operations” on page 13).
