GreenTech GT3000 User Manual

15
Disassembly/Assembly
Disassembly
Tools Required
You will need a #2 Phillips screwdriver.
Workspace Recommendations
A countertop or at surface is ideal for disassembling/assembling your unit. You will
need 2 ft. x 3ft. of clean, accessible workspace. It is recommended to use a small bowl
or cup to hold any screws so they are not lost during the /assembly process.
Disassembly Instructions
1. Turn the unit off.
2. Remove the Power Cord from the wall and rear of the unit.
3. Clean exterior of unit if necessary (see “CLEANING: Unit Exterior” page 17).
Removing the Rear Cover:
1. Using your screw driver, remove the Rear Cover Screw from the Rear Cover (above
the Power Cord Port). Place the Rear Cover Screw where you will nd it easily during
reassembly.
2. Squeeze the tabs on both sides of the Rear Cover (where the grooves are) until
they release and tilt the Rear Cover upwards until the top tab releases. Clean with
compressed air or a damp cloth. Set the Rear Cover aside.
Removing the Filter Assembly:
1. Remove Brass Thumbscrews from the top corners of the Filter Assembly.
Place Brass Thumbscrews where you will nd them easily during reassembly.
2. Grasp the top of the Filter Assembly and tilt away from the unit. Clean if necessary
(see “CLEANING: Filter Assembly” page 17) and set the Filter Assembly aside.
3. Lift tabs on either side of Filter Assembly to remove the rim and access the
separate honeycomb, foam and mesh layers.
Removing the Purication Plate:
Grasp the Purication Plate on the ceramic and gently pull it out of the grooves on the sides.
Clean (see “CLEANING: Purication Plate” page 17) and set the Purication Plate aside.
Removing the PCO Cell:
1. Locate the PCO Cell Power Connector on the right of the rear of the unit almost
halfway up the unit (beside the Purication Plate slot). Squeeze the tabs on the top
and bottom of the PCO Cell Power Connector and pull gently until free from the
PCO Cell Power Connector Outlet.
2. Remove the Thumb Nuts from the Screw Posts on the right and left below the
PCO Cell. Place the Thumb Nuts where you will nd them easily during reassembly.
3. Gently slide the PCO Cell out of the unit. Clean (see “CLEANING: PCO Cell”
page 17) and set the PCO Cell aside.
Clean the interior of the unit (see “CLEANING: Unit Interior” page 17).
Removing the Front Grille:
1. Locate the four Front Grille Screws in the four corners of the Front Grille.
Using your screw driver, carefully remove the four Front Grille Screws. Place the
Front Grille Screws where you will nd them easily during reassembly.
2. Remove the Front Grille carefully to ensure that the Ionization Needle(in the top
center of the front of the unit) is not damaged. Clean the Front Grille if necessary
(using compressed air, vacuum cleaner, damp cloth or warm soapy water)
and set the Front Grille aside.
3. Clean the Ionization Needle if necessary (see “CLEANING: Ionization Needle”).
