SIDE PLATE ANGLE
(See Figure 42)
•
• HOOK – “Grabs” and dulls quickly; increases the potential of KICKBACK. Results from using a
• BACKWARD SLOPE – Needs too much feed pressure; causes excessive wear to the bar and
SIDE PLATE ANGLE
(See Figure 43-45)
• Maintain the depth gauge at a clearance of 1/32" (0.6 mm) Use a depth gauge tool for checking
the depth gauge clearances.
•
•
depth gauge jointer. After lowering each depth gauge, restore original shape by rounding the
•
•
MAINTENANCE
Raker (Depth Gauge) Clearance
HOOK BACKWARD SLOPE
INCORRECT
Restore
Original
Shape By
Rounding
The Front
1/32" (0.6 mm)
Fig. 42
Fig. 44
Fig. 43
Fig. 45
Depth Gauge Jointer
Flat File
To Next Page
