GreenWorks 51142 - TAKING A BREAK; WALL MOUNTING INSTALLATION; Telescopic handle use:

Fig. 16
Fig. 17
MAINTENANCE
TAKING A BREAK
 Engage gun safety lock.
 Turn unit to “OFF” (O) position.
 Unplug the power cord from the outlet.
C A U T I O N :
The use of a pump protector is recommended to prevent cold weather damage during storage
over the winter months.
WALL MOUNTING INSTALLATION (See Figure 16.)
.
 Mark a level line on the wall.
 Mark the position of the holes on the studs
 Mount a desired wall bracket (not included) onto the studs.
 After fastening, make sure the wall bracket is level, and securely mounted on the wall.
I M P O R T A N T
DO NOT USE PRESSURE WASHER WHILE IN WALL MOUNTED POSITION
Telescopic handle use: (See Figure 17.)
 Pull up and fully extend handle for use.
 For transporting, pull as shown.
 To lower handle; push handle until it lock into place for storage.
I M P O R T A N T
This handle is for pulling the unit. Do not lift the unit by this handle.
23
