3. Sharpen the top plate, side plate and depth gauge
with a flat file.
4. File all the cutters to the specified angles and the
same length.
NOTE
During the process:
• Keep the file flat with the surface to be sharpened.
• Use the midpoint of the file bar.
• Use light but firm pressure when sharpening the
surface.
• Lift the file away on each return stroke.
• Sharpen the cutters on one side and then move to
the other side.
Replace the chain if:
• The length of the cutting edges is less than 1/5 in. (5
mm).
• There is too much space between the drive links
and the rivets.
• The cut speed is slow.
• Sharpening the chain many times but it does not
increase the cutting speed. The chain is worn.
10.4 GUIDE BAR MAINTENANCE
NOTE
Make sure that the bar is turned over periodically to
keep symmetrical wear on the bar.
1. Lubricate the bearings on the nose sprocket (if
present) with the syringe (not included).
2. Clean the bar groove with the scraping hook (not
included).
3. Clean the lubrication holes.
4. Remove burr from the edges and level the cutters
with a flat file.
Replace the bar if:
• the groove does not fit with the height of the drive
links (which must never touch the bottom).
• the inside of the guide bar is worn and makes the
chain lean to one side.
11 TRANSPORTATION AND
STORAGE
Before you move the machine, always
• Remove the battery pack from the machine.
• Keep hands clear of the lock-out button.
• Put the scabbard on the guide bar and the chain.
Before you put the machine into storage, always
• Remove all residual oil from the machine.
• Remove the battery pack from the machine.
• Clean all unwanted material from the machine.
• Make sure that the storage area is
• Not available to children.
13
English
EN
