GETTING STARTED
HDMI HYPER
QUICK RELEASE
MOUNTING HYPER QUICK
RELEASE
CONNECT
Using 32mm square M3 pattern to mount
the top part onto the frame or damping
isolator.
STEP 1: The marks on the top part and bottom part must be aligned. The
button on the ring should be aligned with the unlocked icon as shown in the rst
picture.
STEP 2: Keep everything aligned and attach the bottom part to the top part.
STEP 3: Rotate the ring clockwise until hearing a snap, the button should be
automatically popped out and aligned with a locked icon.
