18
Code Meaning Solution Saved
60 Minimum number of Monitored Entrapment Devices
(one) not installed
Review Monitored Entrapment Protection device connections NO
61 CLOSE EYE/INTERUPT held more than 3 minutes Check wired input on main control board Check for
alignment or obstruction
YES
62 CLOSE EYE/EDGE held more than 3 minutes
63 OPEN EYE EDGE held more than 3 minutes
64 CLOSE EYE/INTERUPT held more than 3 minutes Check wired input on expansion board Check for alignment
or obstruction
YES
65 CLOSE EYE/EDGE held more than 3 minutes
66 OPEN EYE EDGE held more than 3 minutes
67 Wireless Edge triggered for more than 3 minutes Check wired input for wiring issue or obstruction YES
68 Wireless Edge loss of monitoring Check Wireless Edge inputs YES
69 Wireless Edge triggered IF an obstruction occurred, no action required. If an
obstruction DID NOT occur, check inputs and wiring
NO
70 CLOSE EYE/INTERUPT triggered, causing reversal,
preventing close, or resetting TTC
IF an obstruction occurred, no action required. If an
obstruction DID NOT occur, check inputs and wiring on main
control board
NO
71 CLOSE EDGE triggered, causing reversal, preventing
close, or resetting TTC
72 OPEN EYE/EDGE triggered, causing reversal,
preventing close, or resetting TTC
73 CLOSE EYE/INTERUPT triggered, causing reversal,
preventing close, or resetting TTC
IF an obstruction occurred, no action required. If an
obstruction DID NOT occur, check inputs and wiring on
expansion board
NO
74 CLOSE EDGE triggered, causing reversal, preventing
close, or resetting TTC
75 OPEN EYE/EDGE triggered, causing reversal,
preventing close, or resetting TTC
80 Close Input (EYE/EDGE) communication fault from
operator
Check inputs and communication methods between
operators, either wired, bus, or radio. Ensure operator is
powered.
May have to erase the wireless communication and
reprogram the two operators.
YES
81 Open Input (EYE/EDGE) communication fault from
operator
82 Close Input (EYE/EDGE) communication fault
(expansion board)
Check the connections between the main board and the
expansion board.
YES
83 Open Input (EYE/EDGE) communication fault
(expansion board)
MPORTANT NOTE:
If a problem is found with an installation, be sure to read the troubleshooting guide thoroughly. If the problem persists call Chamberlain for
technical assistance on 1800 638 234 or email customerservice@chamberlainanz.com in Australia or in New Zealand call 0800 653 667.
See S-Drive manual on how to view error codes.
TROUBLESHOOTING
TROUBLESHOOTING S-DRIVE
