Delivery contents
Pos. Qty. Designation Pos. Qty. Designation
1 1 Lid 18 4 Mounting bracket
2 1 Window (pre-assembled) 19 2 Standing leg
3 2 upper hinge (pre-assembled) 20 2 Wheel leg
4 - - 21 2 Axle
5 2 Spacing sleeve for lid handle 22 2 Wheel
6 1 Lid handle 23 1 Lower shelf
7 2 Bolt M5x60 24 12 Bolt M5x35
8 1 Grill 25 2 Bolt for hinge
9 - - 26 4 Splint
10 1 Burner (pre-assembled) 27 8 M6x10 bolt with integrated sleeve
11 2 Lower hinge (pre-assembled) 28 28 Nut M5
12 - - 29 8 Bolt M5x10
13 1 Fire bowl 30 14 Bolt M5x30
14 2 Side rack 31 2 Heat-resistant washer
15 1 Fat catcher tray 32 1 Holder for the fat catcher tray
16 1 Front panel, assembled with hose,
control knob and adjusting element
33 1 Piezo igniter (A)
17 2 Supporting rod 34 1 Flame tamer
Pack of xing bolts
2x
2x
M5x30
14x
M6x10
8x
M5x35
12x
M5x60
2x
27
24
M5x10
8x
29
30
7
5
31 26
M5
28x
28
4x
2x
25
