Climber 10/ Translation of the original instructions
TRACTION RELEASE LEVER
The traction release device is located at the back of hydrostatic axle (fig. 13). If the machine breaks
down, use the lever under the rear bumper to allow the machine to be towed or moved by hand.
DIFFERENTIAL LOCK ADJUSTMENT
The differential lock must engage when the pedal is half its way (fig. 1, n. 5). To adjust the differential
lock engagement, use the adjusting screw under the platform (fig. 29, ref. A).
MAINTENANCE SUMMARY TABLE
PROCEDURE EVERY 8
HOURS
AFTER
20
HOURS
EVERY
50
HOURS
EVERY
100
HOURS
EVERY 200
HOURS
Engine oil
check the level ●
replace ● ●
Air filter
check ●
replace ٭
Spark plug
check/adjust ●
replace ●
Hydrostatic
axle oil
check the level
● ●
replace ●
(first
change)
●
Check that the engine cooling grid is
clean
●
Check that both engine fins and
cylinders are clean
●
Check that blades are well-
sharpened and well-fixed
●
Lubricate with grease
●
● recommended procedure
٭ procedure to be carried out if necessary
