Climber 9.18/ Translation of the original instructions
WARRANTY
The guarantee is given in compliance with the current law. The dealer will have to give the client a copy
of the registration card of the machine, which they will print up from the Grillo website.
For the engine the guarantee of the relative manufacturers apply.
RECOMMENDED LIST OF SPARE PARTS
2 x mowing blades
2 x blade screws
2 x blade screw nuts
1 x set of belts
1 x air filter for engine
1 x oil filter for engine
TECHNICAL SPECIFICATIONS
MOTOR: B&S INTEK 7180, 15,2 HP (@ 3300 r.p.m.) 656 cm³ OHV twin-cylinder petrol engine.
STARTER: electric with 12V battery.
FUEL TANK: 13 Litres – EMERGENCY SUPPLY: 3 litres.
GEARBOX: hydrostatic transmission with reduction gear and differential.
DIFFERENTIAL LOCK: with pedal engagement.
INTERNAL STEERING RADIUS: 380 mm (±14.9’’).
CLUTCH: electromagnetic with P.T.O and with blade brake.
SPEED: continuously variable from 0 to 9 km/h + reverse speed from 0 to 6 km/h.
TYRES: TRACTOR front 13×5.00-6 puncture-proof treated; rear: 17×8.00-8.
SEAT: sprung and adjustable super-comfort seat with armrests and roll-bar.
BRAKES: front service brakes with pedal engagement; rear parking brake with lever engagement.
CUTTING DECK: rear/side discharge.
CUTTING SYSTEM: rotating with 1 blade.
CUTTING WIDTH: 910 mm (±36’’).
CUTTING HEIGHT: from 30 mm to 90 mm (from ±1.2’’ to ±3.5’’) with 4 different cutting positions and 1
transfer position.
HOURLY CUTTING CAPACITY: approx. 7200 m
2
/h (±1.7 acres per hour).
STANDARD FEATURES: tow bar.
ATTACHMENTS: turf wheels set, 110 cm (±43’’) Quick Shift cutting deck with mulching, rear discharge
and electrical cutting height adjustment, mulching kit for 91 cm (±36’’) cutting deck, 125 cm (±49’’)
orientable snow blade, snow chains for rear wheels.
WEIGHT: 293 kg
SIZE: Length: 1800 mm (±71’’) Width: 990 mm (±38.9’’) Height: 1070 mm (±42.1)
7
