GF3 – Translation of the Original Instructions
GUARANTEE
The guarantee is given in compliance with the current law. The dealer will have to give the client a
copy of the registration card of the machine, which they will print up from the Grillo website.
For the engine the guarantee of the relative manufacturers apply.
TECHNICAL SPECIFICATIONS
ENGINE: - Robin Subaru EX27 265 cc 8,3HP (@ 3600 r.p.m.) one-cylinder 4-stroke petrol;
- LOMBARDINI 15LD350 349 cc 7,5HP (@ 3600 r.p.m.) one-cylinder 4-stroke diesel.
STARTER: recoil starter.
FUEL TANK: 6,1 litres (EX27) – 4,3 litres (15LD350).
GEARBOX: with 6 gears (3 forward gears and 3 reverse gears).
CLUTCH: conic and active clutch
GF3DF version: equipped with differential lock and brakes.
P.T.O: at 965 r.p.m. with anti-clockwise rotation.
HANDLEBAR: with height and side adjustment and mounted on anti-vibration elements.
SAFETY DEVICES: conic active clutch.
CUTTING WIDTH: 110 – 115 – 117 – 127 cm.
WHEELS: TRACTOR wheels 4.00-8/ 4.00-10/ 5.00-10/ – TURF wheels 20×10.00-8.
ATTACHMENTS: 110 – 115 TIROL – 127 cm central cutter bar, 117 cm central double blade bar,
70 cm double-stage snow thrower, 75 cm grass cutter, 68 cm all purpose flail, 125 cm orientable
front blade, 100 cm orientable and tilting sweeper, snow chains for 5.00-10 wheels.
WEIGHT: 115 kg (with EX27) – 127 kg (with 15LD350) – 122 kg (GF3DF version with EX27) – 134
kg (GF3DF version with 15LD350).
SPEED: in km/h with engine running @ 3600 r.p.m.:
WHEELS I° II° III°
4.00 – 8 1,0 2,0 3,0
4.00 – 10 1,2 2,2 3,3
5.00 – 10 1,3 2,4 3,6
PUTTING THE MACHINE INTO SERVICE
1) Check that the machine has not been damaged during transport.
2) Fill the machine PTO flanging all around the coupling with grease.
3) Choose driving handlebar position.
4) Mount wheels and implement.
5) Add engine oil (please always refer to the engine instruction manual).
6) Add gearbox oil (Fig. 4) using MP 80W90 oil, or international equivalent API GL5 oil, US MIL-L-
2105D, quantity 2,2 litres.
7) Insert the control levers.
