GF3 – Translation of the Original Instructions
MAINTENANCE SUMMARY TABLE
PROCEDURE EVERY 8
HOURS
AFTER 20
HOURS
EVERY 50
HOURS
EVERY
100
HOURS
ONCE A
YEAR OR
EVERY 200
HOURS
Engine oil
check the level ●
change ● ●
Air filter
check ●
replace ٭
Spark plug
check/adjust ●
replace ●
Cutter bar
check blade
attachment
●
grease ● ٭
Check that:
-the engine intake grid is clean
-the hydraulic engine cooling fins
are clean
●
Gearbox oil
check the level
●
replace
●
Check that blades are well-
sharpened and well-fixed
● ●
● recommended procedure
٭ procedure to be carried out if necessary
IMPLEMENTS
SNOW THROWER
This implement (Fig. 10) has been especially designed for this particular machine. It is very useful
for clearing snow from yards, driveways, etc. It consists of a turbine rotary unit enclosed in a
special case open at the front, which rotates at high speed, collecting the snow and throwing it
along a pipe. The pipe angle can be adjusted to throw the snow in any direction to a distance of 8 –
10 metres. The snow thrower is fixed to the implement flange. This snow thrower is 60 cm wide
and can clear snow up to 40 cm deep. Wheel weights should be used for best performance. The
two side skids must be adjusted so that they just skim level ground (asphalted streets) or keep the
snow thrower high if the ground is uneven.
Maintenance: when work is over, remove any snow left in the snow thrower so it cannot freeze
and block the turbine. Often check the oil level in the central box. Do not clean the attachment
when the engine is running. Attention, danger! Never touch the snow thrower while it is
working.
ROTARY CUTTER
The 75 cm rotary blade cutter for this machine (Fig. 11) is designed for the maintenance of large
parks and gardens for which a traditional mower would not be appropriate. The high power
available, the driving wheels and three working speeds allow operation in the most difficult
10
