BdYZa<%)*(O$<%)*)OB[\#&$%. 

0$&+,1('$7$

6+((7

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901

02'(/*=+393/$1(5:,7+63,5$/

&877(5+($'

EgdYjXi9^bZch^dch/

Weight.............................................................................................................................................................. 655 lbs.

Width (side-to-side) x Depth (front-to-back) x Height............................................................... 32-1/2 x 42 x 45-7/8 in.

Footprint (Length x Width)..................................................................................................................... 22-1/2 x 22 in.

H]^ee^c\9^bZch^dch/

Type.......................................................................................................................................................... Wood Crate

Content........................................................................................................................................................... Machine

Weight.............................................................................................................................................................. 675 lbs.

Length x Width x Height....................................................................................................................... 31 x 30 x 47 in.

:aZXig^XVa/

Power Requirement........................................................................................................... 220V, Single-Phase, 60 Hz

Minimum Circuit Size........................................................................................................................................ 20 Amp

Switch........................................................................................................ Magnetic with Thermal Overload Protector

Switch Voltage..................................................................................................................................................... 220V

Cord Length............................................................................................................................................................ 5 ft.

Cord Gauge................................................................................................................................................... 12 gauge

Plug Included........................................................................................................................................................... No

Recommended Plug/Outlet Type............................................................................................................... NEMA 6-20

Bdidgh/

BV^c

Type.................................................................................................................. TEFC Capacitor Start Induction

Horsepower................................................................................................................................................ 3 HP

Voltage....................................................................................................................................................... 220V

Phase....................................................................................................................................................... Single

Amps............................................................................................................................................................ 15A

Speed................................................................................................................................................ 3450 RPM

Cycle......................................................................................................................................................... 60 Hz

Number of Speeds............................................................................................................................................ 1

Power Transfer ..................................................................................................................... Triple V-Belt Drive

Bearings......................................................................................................................... Sealed and Lubricated

BV^cHeZX^[^XVi^dch/

DeZgVi^dc>c[d

Max. Cut Width.......................................................................................................................................... 15 in.

Min. Stock Length....................................................................................................................................... 8 in.

Min. Stock Thickness.............................................................................................................................. 3/16 in.

Max. Stock Thickness.................................................................................................................................. 8 in.

No. of Cuts Per Inch............................................................................................................................... 56, 104

No. of Cuts Per Minute............................................................................................................................ 20,000

Cutterhead Speed............................................................................................................................. 5000 RPM

Planing Feed Rate........................................................................................................................... 16, 30 FPM

Max. Cut Depth Planing Full Width......................................................................................................... 3/32 in.

Max. Cut Depth Planing 6 Inch Wide Board............................................................................................. 1/8 in.

G0453Z Machine Data Sheet
