BdYZa<%)*(O$<%)*)OB[\#&$%. 

0$&+,1('$7$

6+((7

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901

02'(/*=3/$1(5:63,5$/&877(5+($'

EgdYjXi9^bZch^dch/

Weight.............................................................................................................................................................. 783 lbs.

Width (side-to-side) x Depth (front-to-back) x Height............................................................... 39 x 55-5/8 x 45-7/8 in.

Footprint (Length x Width)............................................................................................................... 23-1/2 x 19-1/2 in.

H]^ee^c\9^bZch^dch/

Type..................................................................................................................................................................... Crate

Content........................................................................................................................................................... Machine

Weight.............................................................................................................................................................. 932 lbs.

Length x Width x Height........................................................................................................... 29-1/4 x 43 x 46-1/4 in.

:aZXig^XVa/

Power Requirement........................................................................................................... 220V, Single-Phase, 60 Hz

Minimum Circuit Size........................................................................................................................................ 30 Amp

Switch........................................................................................................ Magnetic with Thermal Overload Protector

Switch Voltage..................................................................................................................................................... 220V

Cord Length...................................................................................................................................................... 6-1/2 ft.

Cord Gauge................................................................................................................................................... 12 gauge

Plug Included........................................................................................................................................................... No

Recommended Plug/Outlet Type........................................................................................................................ L6-30

Bdidgh/

BV^c

Type.................................................................................................................. TEFC Capacitor Start Induction

Horsepower................................................................................................................................................ 5 HP

Voltage....................................................................................................................................................... 220V

Phase....................................................................................................................................................... Single

Amps............................................................................................................................................................ 25A

Speed................................................................................................................................................ 3450 RPM

Cycle......................................................................................................................................................... 60 Hz

Number of Speeds............................................................................................................................................ 1

Power Transfer ..................................................................................................................... Triple V-Belt Drive

Bearings......................................................................................................................... Sealed and Lubricated

BV^cHeZX^[^XVi^dch/

DeZgVi^dc>c[d

Max. Cut Width.......................................................................................................................................... 20 in.

Min. Stock Length....................................................................................................................................... 8 in.

Min. Stock Thickness.............................................................................................................................. 3/16 in.

Max. Stock Thickness.................................................................................................................................. 8 in.

No. of Cuts Per Inch............................................................................................................................... 104, 83

No. of Cuts Per Minute............................................................................................................................ 20,000

Cutterhead Speed............................................................................................................................. 5000 RPM

Planing Feed Rate........................................................................................................................... 16, 20 FPM

Max. Cut Depth Planing Full Width........................................................................................................... 1/8 in.

Max. Cut Depth Planing 6 Inch Wide Board............................................................................................. 1/8 in.

G0454Z Machine Data Sheet
