G0547 Combo Sander
1. Sanding Belt
2. Back Stop
3. Dust Port
4. Miter Gauge
5. Disc Sanding Table
6. Sanding Disc
7. Sander Base
8. Tracking Knob
9. Belt Tensioning Lever
10. Bed Angle Release Screw
11. Table Angle Knob
SECTION 4: MACHINE FEATURES
Figure 2. Machine Features.
An important part of safety is knowing your machine and its components. Take the time to familiarize
yourself with the features of your new Model G0547 Combo Sander. They will be frequently mentioned
throughout the instructions in this manual.
