Grizzly G0922 - Section 9: Parts; Main Parts List and Identification

-48-
Model G0922 (Mfd. Since 07/20)
READ ELECTRICAL SAFETY
ON PAGE 44!
Wiring Images (Cont.)
Figure 72. LED light strip.
Figure 74. Motherboard.
Figure 70. Print head.
Figure 71. Touch screen display board.
Figure 73. Filament sensor and feeder.
