Head Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
85 PSW03-1 KNOB 326 P1006326 CLAMP NUT 3/8-16
85V2 PSB01 CAP SCREW 1/4-20 X 5/8 327 P1006327 SPECIAL SCREW 3/8-16 X 38
101 P1006101 CRANK BRACKET 329 P11261103 SPRING COVER ASSY
101-1 P1006101-1 OIL CUP 330 P1006330 SPRING BASE 76 X 76 X 19
101A P1006101A CRANK BRACKET ASSEMBLY 331 P1006331 PINION SHAFT
102 P1006102 WORM SHAFT BUSHING 331-1 PS01 PHLP HD SCR 10-24 X 1/2
131 PB07 HEX BOLT 5/16-18 X 3/4 332A P1006332A FINE FEED CLUTCH ASSEMBLY
132 PW07 FLAT WASHER 5/16 333 P1006333 FINE FEED HOUSING
133 PS04 PHLP HD SCR 1/4-20 X 1/2 333A P1006333-1 FINE FEED ASSEMBLY
134 PB10 HEX BOLT 1/4-20 X 2 334 P1006334 SPRING 27 X 17.5 X 17.5
135 PN05 HEX NUT 1/4"-20 335 P1006335 BEARING SPACER 34 X 28
136 P1006136 GRADUATED ROD ASSY 337-1 P1006337-1 HANDLE BASE ASSY
138 P1014116 FENDER WASHER 1/4 339 P1006339 HANDLE ROD
139 PS01 PHLP HD SCR 10-24 X 1/2 340 P1006340 ROUND KNOB
141 PN08 HEX NUT 3/8"-16 343-1 P1006343-1 HANDWHEEL ASSY
142 PK25M KEY 7 X 7 X 20 344 P1006344 GRADUATED DIAL
143 PSB07 CAP SCREW 5/16-18 X 3/4 345 P1006345 SLEEVE
148 PR05M EXT RETAINING RING 15MM 346 P6202 BALL BEARING 6202ZZ
150 PN04 HEX NUT 5/8"-11 347 P1006347 WORM SHAFT
151 PLW06 LOCK WASHER 5/8 350 P1006350 HEAD WRENCH
154 PR02M EXT RETAINING RING 14MM 351 P1006351 THUMB SCREW 3/8-16
155 PSB05 CAP SCREW 1/4-20 X 3/4 352 PB46 HEX BOLT 5/8-11 X 6
156 PB03 HEX BOLT 5/16-18 X 1 356 P1006356 ON/OFF SWITCH
157 PB38 HEX BOLT 7/16-14 X 2 358 P1006358 ELEVATION CRANK
158 PN02 HEX NUT 5/16"-18 359 P1006359 WORM GEAR SHAFT
159 P1006159 KEY 7 X 7 X 37 360 P1006360 PINION GEAR
160 PB11 HEX BOLT 5/16-18 X 1-1/2 361 P1006361 GEAR AXLE
161 PW07 FLAT WASHER 5/16 362 P1006362 COMPRESSION SPRING 13 X 83
162 PB12 HEX BOLT 5/16-18 X 1-1/4 363 P1006363 MOTOR POSITION PIN
163 PS04 PHLP HD SCR 1/4-20 X 1/2 366 P1006366 MOTOR BASE
164 P1006164 FRONT COVER PLATE ASSEMBLY 367V2 P1006367V2 2HP MOTOR 110/220V SINGLE PHASE
301 P1126102 DRAWBAR 7/16-20 x 442L 367V2-1 P1006367-1 MOTOR FAN COVER
302 P1006302 SPINDLE NUT 42-16 V1.08.97 367V2-2 P1006367-2 MOTOR FAN
303 P1006303 SPINDLE PULLEY 367V2-3 P1006367-3 CIRCUIT BREAKER BUTTON
304-1 P1006304-1 SPEED CHART LABEL 367V2-4 P1006367-4 JUNCTION BOX
304A P1006304A BOTTOM BELT COVER 367V2-5 P1006367V2-5 S CAPACITOR 500M 250V 1-3/8 X 2-3/4
305 P1006305 OUTER BEARING COVER 367V2-6 P1006367V2-6 S CAPACITOR COVER
306A P1006306A TAPERED SPINDLE SLEEVE LH V2.12.98 367V2-7 P1006367V2-7 R CAPACITOR 50M 250V 1-3/8 X 2-3/4
309 PR52M EXT RETAINING RING 80MM 367V2-8 P1006367V2-8 R CAPACITOR COVER
310A P1006310A IDLER PULLEY ASSEMBLY 370-1 P1006370-1 MOTOR PULLEY SET
311 P1006311 HEAD CASTING 371A PVB33 V-BELT B-33
312 P1006312 RUBBER RING 374A PVB42 V-BELT B-42
313 P1006313 QUILL COLLAR 376 P1006376 PULLEY SWING BASE
314 P1006314 TAKE UP NUT 377 P1006377 CLIP PLATE
315 P30206 TAPERED ROLLER BEARING 30206 379 P1006379 RUBBER COLLAR
316 P1006316 QUILL 386 P1006386 FACE CUTTER
316A P1006316A QUILL ASSEMBLY 392 P1006392 POSITION SET BRACKET
317 P1006317 SPINDLE SHAFT 393A P1006393A FIXED NUT
317-1 P1006317-1 SPECIAL STAR WASHER 662 P1006662 DRAW BOLT COVER 75 X 54 X 42.5
318 P1006318 BEARING 30207J 692 P1006692 BELT COVER LID
319 P1006319 BEARING CAP 701 PLW02 LOCK WASHER 1/4
320-1 P1006320-1 CUTTER ARBOR ASSY 702 PW06 FLAT WASHER 1/4
321 P1006321 CHUCK ARBOR 703 P1006703 LIMIT PLATE
322 P1006322 HANDLE BOLT 3/8-16 704 P1006704 FLAT WASHER 1/8
324 P1006324 QUILL LOCK HANDLE 705 P1006705 PHLP HD SCR 5-40 X 3/8
324-1 PW01 FLAT WASHER 1/2 706 P1006706 CHUCK 1/2"-JT6
325 P1006325 CLAMP COLLAR 713 P1006713 CHUCK KEY
