G4000 9'' x 19'' Lathe -15-
FFiigguurree 1188..
Threading dial and half nut lever.
HHaallff NNuutt LLeevveerr --
This lever compresses and
releases the half nut that engages the leadscrew.
The lever is only engaged while turning threads
in stock. A lockout device featured in the lever
mechanism engages when the feed selector is
used.
FFiigguurree 1188..
TThhrreeaaddiinngg DDiiaall IInnddiiccaattoorr --
The indicator tells
you when to engage the half nut to begin the
threading process.
FFiigguurree 1188..
LLeevveerr
TThhrreeaadd DDiiaall
NNOOTTIICCEE
Do not simultaneously engage the feed lever
and the threading lever. Doing so will damage
the lathe.
FFiigguurree 1177..
Longitudinal feed lever.
FFeeeedd SSeelleeccttoorr --
Moving this lever upward
engages the automatic longitudinal feed.
FFiigguurree
1177..
