GRIZZLY MODEL G4000 9" X 19" BENCH LATHE
MACHINE DATA
SHEET
Design Type .................................................................................................... Bench Model
Overall Dimensions:
Overall Length .......................................................................................................
36
1
⁄2"
Overall Width ............................................................................................................
22"
Height ......................................................................................................................15"
Bed Width ................................................................................................................
4
1
⁄2"
Spindle Bore ..............................................................................................................
3
⁄4''
Spindle Taper ......................................................................................# 3 Morse Taper
Tailstock Taper ....................................................................................# 2 Morse Taper
Weight (Net) ..................................................................................................... 250 lbs.
Weight (Shipping) ............................................................................................. 300 lbs.
Crate Size .................................................................................. 41" L x 22" W x 19" H
Footprint ..........................................................................................................37" x 16"
Construction: ....................................................................................................... Cast Iron
Capacity:
Swing Over Bed .........................................................................................................
9''
Swing Over Saddle ....................................................................................................
5''
Carriage Travel .........................................................................................................
16"
Max Tool Size ....................................................................................................
1
⁄2'' x
1
⁄2''
Distance Between Centers ......................................................................................
19''
Lead Screw ................................................................................................
9
⁄16'' - 16 TPI
Spindle Thread ..................................................................................... 39 mm X 4 mm
Compound Travel ....................................................................................................
1
7
⁄8''
Cross Slide Travel ...................................................................................................
4
1
⁄4''
Tailstock Barrel Travel ............................................................................................
1
9
⁄16''
Spindle Speeds ..................................................130, 300, 400, 600, 1000, 2000 RPM
Feed Rate Range .......................................................................... 18 @ .0023'' - .013''
Thread Range Inch .......................................................................27 @ 8 TPI - 56 TPI
Thread Range Metric ........................................................................ 11 @ .5 - 3.0 mm
Motor:
Type ............................................................................ TEFC Capacitor Start Induction
Horsepower ................................................................................................................
3
⁄4
Phase ⁄ Hertz .................................................................................Single Phase ⁄ 60Hz
Voltage .................................................................................................................. 110V
Amps ...................................................................................................................... 11.6
RPM ...................................................................................................................... 1725
Bearings ....................................................................Shielded And Lubricated For Life
Standard Accessories:
.......................................................................... 4'' 3-Jaw Chuck w ⁄ Two Sets of Jaws
........................................................................
7
1
⁄4''' 4-Jaw Chuck w ⁄ Reversible Jaws
........................................................................................4-Way Tool Post ⁄ Face Plate
.............................................................................................Follow Rest ⁄ Steady Rest
..................................................................................... # 2 Morse Taper Dead Center
..................................................................................... # 3 Morse Taper Dead Center
........................................................................................ # 2 Morse Taper Live Center
................................................................................................. Extra C-Type Tool Post
........................................................................................................Tool Box & Tool Kit
Specifications, while deemed accurate, are not guaranteed.
REVISED 5/99
