-42-
Model G4002/G4003 (Mfd. Since 3/14)
SECTION 9: PARTS
Electrical
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P4002001 START BUTTON 52 P4002052 CONTACTOR GSC1CJX4-D 110V
2 P4002002 INDICATOR LIGHT 53 P4002053 CONTACTOR JZC3-40D 110V
3 P4002003 JOG BUTTON 54 P4002054 FUSE HOLDER
4 P4002004 RESET BUTTON 55V2 P4002055A CONTROL PANEL PLATE V2.03.07
50 P4002050 THERMAL PROT. BLOCK 933 P4002933 FUSE 2 AMP
51 P4002051 TRANSFORMER
