Model G4003
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G4003 12" X 36" GEAR‐HEAD, CAM LOCK SPINDLE,
LATHE
Product Dimensions:
Weight.............................................................................................................................................................. 917 lbs.
Width (side-to-side) x Depth (front-to-back) x Height........................................................................... 61 x 23 x 23 in.
Footprint (Length x Width)............................................................................................................................ 61 x 23 in.
Shipping Dimensions:
Type.......................................................................................................................................................... Wood Crate
Content........................................................................................................................................................... Machine
Weight............................................................................................................................................................ 1020 lbs.
Length x Width x Height....................................................................................................................... 29 x 66 x 29 in.
Must Ship Upright................................................................................................................................................... Yes
Electrical:
Power Requirement........................................................................................................... 220V, Single-Phase, 60 Hz
Prewired Voltage.................................................................................................................................................. 220V
Full-Load Current Rating........................................................................................................................................ 12A
Minimum Circuit Size.............................................................................................................................................. 15A
Connection Type....................................................................................................................................... Cord & Plug
Power Cord Included............................................................................................................................................... No
Recommended Power Cord............................................................................... “S”-Type, 3-Wire, 14 AWG, 300 VAC
Plug Included........................................................................................................................................................... No
Recommended Plug Type..................................................................................................................................... 6-15
Switch Type............................................................................................ Control Panel w/Magnetic Switch Protection
Motors:
Main
Horsepower................................................................................................................................................ 2 HP
Phase............................................................................................................................................ Single-Phase
Amps........................................................................................................................................................... 8.5A
Speed................................................................................................................................................ 1725 RPM
Type................................................................................................................. TEFC Capacitor-Start Induction
Power Transfer .................................................................................................................................. Belt Drive
Bearings..................................................................................................... Shielded & Permanently Lubricated
Centrifugal Switch/Contacts Type.......................................................................................................... Internal
Main Specifications:
Operation Info
Swing Over Bed......................................................................................................................................... 12 in.
Distance Between Centers........................................................................................................................ 36 in.
Swing Over Cross Slide............................................................................................................................... 7 in.
Swing Over Saddle...................................................................................................................................... 7 in.
Maximum Tool Bit Size............................................................................................................................. 5/8 in.
Compound Travel.................................................................................................................................. 3-1/4 in.
Carriage Travel.................................................................................................................................... 30-1/2 in.
Cross Slide Travel................................................................................................................................. 6-1/4 in.

Grizzly G4002 Specifications

General

Brand	Grizzly
Model	G4002
Category	Lathe
Language	English
