G4002/3 Gear Head Lathes -47-
REF PART # DESCRIPTION
801 P4002801 COVER
802 P4002802 SCREW
803 P4002803 NUT
812 P4002812 MOTOR 2 HP
813 PW04M FLAT WASHER 10MM
814 P4002814 SCREW
815 P4002815 KEY
816 P4002816 PULLEY
817 P4002817 MOTOR MOUNT BRKT
818 P4002818 FLAT WASHER
819 P4002819 HEX BOLT
