Grizzly G7943 Parts Manual

G7943/G7944 12 Speed Heavy-Duty Drill Press
-43-
REF PART # DESCRIPTION REF PART # DESCRIPTION
53 P7943053 SLIDE BAR 83 P7943083 ROUND NUT M17 X 1
54 P7943054 SLIDE BAR 84 P7943084 WASHER
55 P7943055 MOTOR BASE 85 P6203 BALL BEARING 6203ZZ
56 PW06M FLAT WASHER 12MM 86 P7943086 RUBBER WASHER 62 X 50 X 2
56A PLW05M LOCK WASHER 12MM 87 P7943087 SPINDLE SLEEVE
57 PN09M HEX NUT M12-1.75 88 P6205 BALL BEARING 6205ZZ
58 P7943058 MOTOR 89 P7943089 SPINDLE
58-1 P7943058-1 CAPACITOR COVER 90 P7943090 ARBOR
58-2 P7943058-2 CONNECTION BOX 91 P7943091 CHUCK
58-3 P7943058-3 MOTOR COVER 92 P7943092 CHUCK KEY
58-4 P7943058-4 MOTOR FAN 93 P7943093 LIGHT BODY
58-5 P7943058-5 CAST IRON MOTOR END BELL 94 P7943094 LIGHT BASE
58-6 P7943058-6 S CAPACITOR 200 MFD 125VAC 94A PS06M PHLP HD SCR M5-.8 x 20
59 P7943059 MOTOR PULLEY 95 P7943095 LIGHT SCREW
60 PK34M KEY 5 X 20 96 P7943096 SWITCH PLATE
61 PSS01M SET SCREW M6-1 X 10 97 P7943097 SWITCH (LIGHT)
62 PVM25 V-BELT M-25 3L250 98 PSW06 SWITCH 110/220V
63 P7943063 CENTER SHAFT 98B P7942020A YELLOW SWITCH KEY
64 P6202 BALL BEARING P6202 99 PR22M INT RETAINING RING 38MM
65 P6202 BALL BEARING P6202 100 P7943100 PWRCRD110L
66 PR05M EXT RETAINING RING 15MM 100B P7943100B STRAIN RELIEF
67 P7943067 CENTER PULLEY 100C P7946100C MOTOR CORD
68 PW03M FLAT WASHER 6MM 101 PAW05M HEX WRENCH 5MM
68B PW03M FLAT WASHER 6MM 102 PAW03M HEX WRENCH 3MM
69 PS68M PHLP HD SCR M6-1 X 10 103 P7943103 DRIFT KEY
70 PS05M PHLP HD SCR M5-.8 x 8 104 P7943104 LIGHT WARNING LABEL
71 PW02M FLAT WASHER 5MM 105 P7946105 WARNING/ID LABEL
72 P7943072 KNOB 106 P7943106 SPEED CHART LABEL
73 P7943073 PULLEY COVER 107 P7943107 GRIZZLY BLACK/AL LABEL
74 PVM25 V-BELT M-25 3L250 110 P7943110 LOCK WRENCH
75 P7943075 PULLEY NUT 113 P7943113 ANGLE SCALE
76 P7943076 SPINDLE PULLEY 114 PS05M PHLP HD SCR M6-1 X 8
77 P7943077 INSERT PULLEY 115 PSB14M CAP SCREW M8-1.25 X 20
78 PR38M INT RETAINING RING 62MM 116 P7943116 STRAIN RELIEF
79 P6205 BALL BEARING 6205ZZ 117 P7943117 DRILL PRESS LABEL
80 P7943080 SPACER 118 P7943118 INDICATOR
81 P6205 BALL BEARING 6205ZZ 119 P7943119 MOTOR LABEL
82 PR38M INT RETAINING RING 62MM 120 P7943120 CRANK LEVER
