Grizzly G7945 Parts Manual

G7945/G7946 Radial Drill Press
-41-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P7945001 BASE 72-1 P7945072-1 CRANK HANDLE
3 PB09M HEX BOLT M8-1.25 X 20 73 PSS01M SET SCREW M6-1 X 10
4 P7945004 SHORT RACK 74 P7945074 10T GEAR
5 P7945005 SHORT VERTICAL COLUMN 78 P7945078 10MM CAPSCREW
7 P7945007 GEARED TABLE BRACKET 80 P7945080 COLUMN RING
7-1 P7945007-1 COMPLETE TBL BRKT ASSY 83 P7945083 SQUARE TABLE
11 P7945011 CLAMP BOLT M10-1.5 X 30 93-1 P7945093-1 HEX BOLT M8-1.25 X 125
13 P7945013 HORIZONTAL COLUMN BRKT 97 P7945097 WING NUT 8MM
70 P7945070 PIN 112 PLW06M LOCK WASHER 10MM
71 P7945071 WORM SHAFT 123 P7945123 SPECIAL WRENCH
72 P7943006 HANDLE
G7945 Parts List
