OM/SM-EE-CE 7
OM/SM-EE(CE)
3.0 Installation
The Groen Kettle is provided with complete internal
wiring and is ready for immediate connection. Wiring
diagrams are provided in this manual and on the
inside of the control housing service panel. Any
mechanical or electrical changes must be approved
by Groen’s Food Service Engineering Department.
The completed unit has been operated at the factory
to test all controls and heater elements.
3.1 Set the kettle in place and level it by turning the
bullet feet to adjust leg length. Allow clearance
around the unit for cleaning, maintenance and
service.
3.2 Confirm that the jacket water level is above the
mid point of the gauge glass. If the level is low,
follow the instructions under “Jacket Filling and
Water Treatment,” Page 12.
3.3 The open end of the elbow
on the outlet of the safety
valve must face downward.
If it does not, turn it to the
correct position.
3.4 Provide electrical power specified on the
equipment electrical information plate. Observe
local codes and/or The National Electrical Code
in accordance with ANSI/NFPA 70 - (current
edition).
3.5 The equipment is shipped ready for three
phase operation. Check wiring diagram label
for correct phase. Contact factory for single
phase conversion.
3.7 Equipotential Terminal - In accordance with
national regulations, the unit has been fitted
with an equipotential terminal.
The quipotential terminal is located near the
bottom of the Control Panel.
WARNING
INSTALLATION OF THE KETTLE MUST
BE DONE BY PERSONNEL QUALIFIED
TO WORK WITH ELECTRICITY. IMPROPER
INSTALLATION CAN RESULT IN INJURY
TO PERSONNEL AND/OR DAMAGE TO
EQUIPMENT
DANGER
ELECTRICALLY GROUND THE UNIT AT
THE TERMINAL PROVIDED. FAILURE
TO GROUND UNIT COULD RESULT IN
ELECTROCUTION AND DEATH.
EQUIPOTENTIAL
TERMINAL
POWER
SUPPLY
Control Panel (EE-20 Shown)
3.6 Bring in the electrical supply through opening on
control housing that is located below the thermostat
dial (see photograph on page 5). An opening is
provided for 1-1/4” (35 mm) conduit fitting.
Water tight, 90° elbow connection is recommended.
Incoming power connections are made at the
terminal block.
Observe local codes and/or the National
Electrical Code in compliance with ANSI/NFPA
70 (latest edition). When there is a choice
between applicable codes, Groen recommends
following the more stringent code. (A BX
connection is not recommended.)
