OM-TDB/7
20
l. Parts List
(For units manufactured before September 1, 1988) *
To order parts, contact your Groen Certified Service Agency. Supply the model designation, part
description, part number, quantity, and, where applicable, voltage and phase.
Key Description Part No. Key Description Part No.
1 Kettle Assembly TDB/7-20 003144 24 Street EL 1/4” IPS X 90” 010668
Kettle Assembly TDB/7-40 003145 25 Block, Pillow, 1-½” 002989
2 Base Assembly 054174 26 Collar, Set 003118
3 Bottom Cover 003141 27 Set Screw 3/8” - 16NC x ½” 003117
4 Gasket, U-channel 007937 28 Micro Switch 002982
5 Pedestal Weldment 002990 29 Bracket, Micro Switch 002988
6 Pedestal Cladding, 480V Only 003148 30 Contactor
(See table)
Pedestal Cladding, 208-240V 003147 31 Transformer 012827
7 Screw #8 X ½” 005002 32 Fuse, 3 AMP, 480V Only 002651
8 Cap, Pedestal 003137 33 Terminal Block, 208-240V 002864
9 Cover, TDB/7-40 003136 Terminal Block, 480V 003119
Cover, TDB/7-20 003139 34 Fuse Holder 002944
10 Screw, RHMS #8-32 X 3/8” 005724 35 Fuse
(See table)
11 Nut, KEPS 1/4” X 20 NC 012940 36 Screw, RHMS #8-32 X 3/4” 012656
12 Handle Assembly 012695 37 Spacer 003146
Ring, Tolerance 012692 38 Screw Hex Head ½”-13 NCx3½” 003285
13 Bumper, TDB/7-40 003248 39 Nut, Hex ½” - 13 NC 005705
Bumper, TDB/7-20 003241 40 Lock Washer ½” 005735
14 Washer (As Required) 003242 41 Pressure Gauge 001594
Washer (As Required) 003243 42 Fittings, Gauge Glass 002845
15 Screw, Hex Head ½” - 13 NC X 1” 005622 43 Rubber Gauge Glass Gasket 008917
16 Thermostat 012313 44 Washer (With Item 42)
Õ
17 Screw, RHMS #6-32 NC X ½” 012603 45 Hex Nut (With Item 42) Õ
18 Knob, Thermostat 002868 46 Glass, Gauge 002987
19 Pilot Light, 208-240V 016028 47 Rod, Gauge Glass Guard 003127
Pilot Light, 480V 002986 48 Nut, Dome #10 - 24 NC 005470
20 Basket for TDB/7-20 001607 49 Thermostat, High Limit 004588
Basket for TDB/7-40 001121 Bracket, Bottom 002916
21 Cover, One Piece Lift-off, TDB/7-40 013496 Grommet, Thermostat 001518
Cover, One Piece Lift-off, TDB/7-20 001566 Grommet, Trunnion 003492
22 Knob, Maroon Ball 012691 Grommet 007400
23 Valve, Safety 005587 Elbow 004185
ELECTRICAL PARTS TABLE
Model KW AMP Contactor Pilot Light Transformer Wire Harness Fuse
TDB/7-20
208V/1 Ph 6.3 31 009173 016028 None 003175 002945
240V/1 Ph 6.3 27 009178 016028 None 003175 002945
480V/1 Ph 6.3 14 009576 002986 012827 003172 002651
208V/3 Ph 6.3 18 009210 016028 None 003174 002945
240V/3 Ph 6.3 16 009210 016028 None 003174 002945
480V/3 Ph 6.3 8 009574 002986 012827 003170 002651
TDB/7-40
208V/1 Ph 10.8 52 013368 016028 None 003168 002945
240V/1 Ph 12 50 013368 016028 None 003168 002945
480V/1 Ph 12 25 009576 002986 012827 003166 002651
208V/3 Ph 10.8 30 009210 016028 None 003167 002945
240V/3 Ph 12 30 009210 016028 None 003167 002945
480V/3 Ph 12 15 009574 002986 012827 003165 002651
* Date of manufacture is stamped on National Board data plate.
