OM-TDB/7
24
Parts List
(For units manufactured between July 1, 1992 and Feb. 6, 1995) *
To order parts, contact your Groen Certified Service Agency. Supply the model designation, part
description, part number, quantity, and, where applicable, voltage and phase.
Key Description Part No. Key Description Part No.
1 Kettle Assy. TDB/7-20 003144 25 Block, Pillow, 1-½” 002989
Kettle Assy. TDB/7-40 003145 26 Collar, Set 003118
2 Base Assy, TDB/7-20 003135 27 Set Screw 3/8” - 16 NC X ½” 003117
Base Assy, TDB/7-40 003206 28 Micro Switch 002982
3 Bottom Cover 003141 29 Bracket, Micro Switch 002988
4 Gasket, U-channel 007937 30 Contactor
(See table)
5 Pedestal Weldment 002990 31 Transformer 480V Only (See table)
6 Pedestal Cladding, 480V Only 003148 32 Fuse 3 AMP, 480V Only (See table)
Pedestal Cladding, 208-240V 003147 33 Terminal Block 088214
7 Screw #8 X ½” 005002 34 Fuse Holder 208-240V 002944
8 Cap 003137 35 Fuse 208/240V
(See table)
9 Cover, TDB/7-40 003136 36 Screw, RHMS #8-32 X 3/4” 012656
Cover, TDB/7-20 003139 37 Spacer 003146
10 Screw, RHMS #8-32 X 3/8” 005724 38 Screw Hex Head ½”-13 NC x
3½”
003285
11 Nut, KEPS 1/4” X 20 NC 012940 39 Nut, Hex ½” - 13 NC 005705
12 Handle 012695 40 Lock Washer ½” 005735
13 Bumper, TDB/7-40 003248 41 Pressure Gauge 084208
Bumper, TDB/7-20 003241 42 Fittings, Gauge Glass 002845
14 Washer (As Required) 003242 43 Rubber Gauge Glass Gasket 008917
Washer (As Required) 003243 44 Washer (With Item 42)
Õ
15 Screw Hex Head ½”-13 NC X 1” 005622 45 Hex Nut (With Item 42) Õ
16 Thermostat 012313 46 Glass, Gauge 002987
17 Screw, RHMS #6-32 NC X ½” 012603 47 Rod, Gauge Glass Guard 003127
18 Knob, Thermostat 002868 48 Nut, Dome #10 - 24 NC 005470
19 Pilot Light
(See table) 49 Thermostat, High Limit 004588
20 Basket
Õ 50 1/4 NPT Full Coupling 093306
21 Cover
Õ 51 1/4 NPT Nipple X 2” Long 010281
22 Knob
ÕÕWater Fill Assy. 096914
23 Valve, Safety 097005
Õ Water Level Probe 015589
24 Street EL 1/4” IPS X 90” 010668
Õ Low Water Cutoff
208V/240V/480V
096925
ELECTRICAL PARTS TABLE
Model KW AMP Contactor Pilot Light Transformer Wire
Harness
Fuse
TDB/7-20
208V/1 Ph 6.3 31 013369 016028 NONE 083649 002945
240V/1 Ph 6.3 27 013369 016028 NONE 083649 002945
480V/1 Ph 6.3 14 013369 016028 086876 083649 086881
208V/3 Ph 6.3 18 013369 016028 NONE 083649 002945
240V/3 Ph 6.3 16 013369 016028 NONE 083649 002945
480V/3 Ph 6.3 8 013369 016028 086876 083649 086881
TDB/7-40
208V/1 Ph 10.8 52 013369 016028 NONE 083649 002945
240V/1 Ph 12 50 013369 016028 NONE 083649 002945
480V/1 Ph 12 25 013369 016028 086876 083649 086881
208V/3 Ph 10.8 30 013369 016028 NONE 083649 002945
240V/3 Ph 12 30 013369 016028 NONE 083649 002945
480V/3 Ph 12 15 013369 016028 086876 083649 086881
* Date of manufacture stamped on National Board data plate.
