OM-TDB/7
29
Parts List
(For units manufactured after Feb. 6, 1995) *
To order parts, contact your Groen Certified Service Agency. Supply the model designation, part
description, part number, quantity, and, where applicable, voltage and phase.
Key Description Part No. Key Description Part No.
1 Pedestal Cover 003137 30 Insulator Board 003490
2 Pedestal Weldment 002990 31 Tilt Switch Bracket 002982
3 Pillow Block 002989 32 Hex Nut #4-40 003121
4 Set Collar 003118 33 Terminal Block 088214
5 Set Screw 5/8” LG 003440 34 Screw #6-32 X ½” LG 012603
6 Grommet 003492 35 Pilot Lamp 016028
7 Electrical Mounting Bracket 086873 36 Bullseye Sightglass 108554
8 Bolt ½-13 X 3-½ “ LG 003285 37 Thermostat Knob 002868
9 Bolt 3/8 - 16 X 1-½” LG 005703 38 Thermostat 012313
10 Pedestal Cladding 208/240 Volt 003147 39 Water Level Probe 015589
10A Cover Plate 480 Volt Fuse Holders 088212 40 Bottom Cover 003141
11 Hex Nut 3/8 - 16 008214 41 Hex Nut 1/4-20 012940
12 Pedestal Cover 003139 42 Pressure Switch 096963
13 Bumper TDB/7-20 101560 43 Hex Reducing Bushing½NPTx1/4 NPT 008739
13A Bumper TDB/7-40 003268 44 Elbow Assembly 101543
14 Base Assembly 054174 45 Bottom Cover Bracket 002916
15 Hex Nut ½-13 005705 46 Screw #6-32 X 3/8” LG Round Head 009697
16 Bolt ½-13 X 3/4” LG 005070 47 Thermostat Adapter 107172
17 Weldment Spacer 003146 48 Gasket Bottom Cover 007937
18 Sheet Metal Screw #8 Truss Hd. 005002 49 Safety Valve 097005
19 Screw #8-32 X 1-1/4” LG 005056 50 Pressure Gauge 084208
20 Contactor 013369 50A Pressure Gauge Lens 087635
21 Screw #8-32 X 3/8” LG 006971 51 Water Fill Assembly 101528
22 Transformer 480 Volt 086876 52 Kettle Body Wire Harness 096938
22A Fuse 480 Volt Only 086881 53 Handle Assembly 012695
23 Fuse Holder 002944 53A Ball Knob 012691
24 Fuse 002945 53B Tolerance Ring 012692
25 Screw #8-32 X 3/4” LG. 012656 53C Handle Rod 013597
26 Water Level Control Board 096925 x Nickel Plt Heating Element Nut 084202
27 Set Screw ½” LG 003117 x Nickel Plt Heating Element Screw 084201
28 Tilt Screw 002982 x Line Side Harness 088210
29 Screw #4-40 X 3/4” LG 003122
* Date of manufacture stamped on National Board data plate.
x - Not Shown
