Technical information
2. Technical information
2.1. Power supply information
Nominal voltage (long-term usage)
230 V AC
Permitted voltage range
(short-term usage)
195 V to 264 V
Power consumption
1
0.56 A (EV-301)
1.12 A (EV-601)
Min. series fuse (on site) ≥ C 16 A
Connected load
103 VA (EV-301)
206 VA (EV-601)
Inrush current
approx.10 A (EV-301)
approx. 20 A (EV-601)
Frequency range 47 Hz to 63 Hz
Main fuse (internal)
Fuse characteristic
Type T 1.25 A
Power supply line cross section at least 1.5 mm²
Clamp format 0.5 mm² - 2.5 mm²
(1) Power consumption during maximum load of the supply system
2.2. Output information for motor channels
switch-on duration
30%
(ON: 3 min / OFF: 7 min)
Output voltage mains operation
(nominal)
24 V DC
Permitted voltage range
(mains operation)
23.0 V DC to 24.5 V DC
Output voltage battery operation
(nominal)
24 V DC
Permitted voltage range
(battery operation)
21 V DC to 28.6 V DC
Output current I
out
(short-term
operation)
(I
out
= I
mot1
+ I
mot2
)
3 A (EV-301)
6 A (EV-601)
Power output (non-stop operation)
50 W (EV-301)
100 W (EV-601)
Power output
(short-term operation)
73.5 W (EV-301)
145 W (EV-601)
Output fuse for actuators
Type T 3.15 A (EV-301)
Type T 6.3 A (EV-601)
Ripple of the output voltage Vpp
(0 A < I
out
< 3 A)
≤ 500 mVpp
Power outage bridge-over time
1
10 ms
Return current in emergency power
operation (battery stress by the
EV-x01)
19 mA
Clamp format 0.5 mm² - 2.5 mm²
(1) Input voltage 195 V AC; load current 3 A / 6 A
2.3. Standardsandcertications
EN compliant As per EMC directive
2014 / 30 / EU and the
low voltage directive
2014 / 35 / EU
UK compliant As per Electromagnetic
Compatibility Regulations
2016 and Electrical Equip-
ment (Safety) Regulations
2016
Additional registrations,
certicates
1
prEN 12101-9
BS ISO 21927-9
BS EN 12101-10
Classication as per EN 12101-9 Class D
Classication as per EN 12101-10 Class A
Environmental class as per
EN 12101-10
1
2.4. Connection information for Override
Switch (EV-HE077)
Maximum number of
main emergency switch (EV-HE077)
2
Output voltage range (B1) Clamp 8 17.5 V DC to 18 V DC
Current carrying
capacity (B1)
Clamp 8 max. 120 mA
Monitoring current
(OK- range)
Clamp 8 100 μA to 5 mA
Output voltage range
(OK at S1)
Clamp 9 16 V DC to 20 V DC
Output voltage range
(Failure at S1)
Clamp 9 11 V DC to 15 V DC
Output voltage range
(Alarm at S1)
Clamp 9 6 V DC to 10 V DC
Current carrying capacity (S1) Clamp 9 max. 100 mA
Input voltage range (A1) Clamp 10 15 V DC to 30 V DC
2.5. Override Switch EV-HE077
Operating time Reset
Close-
switch
Press > 5 Seconds
Operating time
override
Close-
switch
Press 2 - 5 Seconds
Rated voltage range (B1) 5 V DC to 28.2 V DC
Current consumption
Condition (OK)
Clamp B1 0.5 mA to 5 mA
Current consumption Over-
ride
Clamp B1 8 mA to 12mA
Current consumption Alarm Clamp B1 28 mA to 32 mA
EOL resistor
Clamp B1
Clamp “˗”
27 kΩ ± 5%
Current consumption in
mains failure mode
Clamp S1 3 mA
Mute mode ca. 24 h
Piezo buzzer (sound pressure, measure
distance 1 m, without housing)
65 to 70 dB(A)
2.6. Connection information for Fire Alarm
System (FAS)
Output voltage range (B3)
Clamp 28 17.5 V DC to 18 V DC
Current carrying capacity (B3) Clamp 28 max. 120 mA
Monitoring current (OK-range) Clamp 28 100 μA to 5 mA
Reset time after SHEV - reset
(by disconnecting from mains
B3)
Clamp 28 3 sec
Input voltage range (A3)
Clamp 30 15 V DC to 30 V DC
2.7. Connection information for smoke
detector EV-SD
Maximum number 2 × EV-SD
Output voltage range (B2) Clamp 25 17.5 V DC to 18 V DC
Current carrying
capacity (B2)
Clamp 25 max. 120 mA
Monitoring current (OK range) Clamp 27 100 μA to 5 mA
Reset time after SHEV-reset
(by disconnecting from mains
B2)
Clamp 25 3 sec
Autoreset when triggered
by smoke detector
30 min
Input voltage range (A2) Clamp 27 15 V DC to 30 V DC
