GROUP SCS EV-601 - Connection Information for Wind-, Rain- Detector (EV-WRS); Connection Information for Ventilation Switch; Connection Information for Feedback Input; Connection Information for Volt-Free Contacts NO; C; N C

Technical information
SCS_BA_EV-301_601_EN_12 groupscs.co.uk Date: 31.05.2023
info@groupscs.co.uk Issue: 1.2 / 06.2023
Page 8
2.8. Connection information for wind-, rain-
detector (EV-WRS)
Maximum number 1
Output voltage range (ES) Clamp 13 23.0 V DC to 24.5 V DC
Current carrying capacity (ES) Clamp 13 max. 150 mA
Input voltage range (LZ) Clamp 14 15 V DC to 30 V DC
2.9. Connection information for ventilation
switch
Output voltage range (E) Clamp 15 23.0 V DC to 24.5 V DC
Current carrying capacity (E) Clamp 15 max. 15 mA
Input voltage range (Z) Clamp 16 15 V DC to 30 V DC
Input voltage range (A) Clamp 17 15 V DC to 30 V DC
2.10. Connection information for feedback
input
Input voltage range (F) Clamp 21 15 V DC to 30 V DC
2.11. Connection information for volt-free
contacts“NO / C / NC”
Voltage capacity of switching
contact 1
(C - NO)
Clamp 6
on
Clamp 5
max. 30 V DC
Voltage capacity of switching
contact 1
(C - NC)
Clamp 6
on
Clamp 7
max. 30 V DC
Current carrying capacity
(C - NO resp. C - NC) – Resistive load
max. 2 A DC
Voltage capacity
60 W
62.5 VA
2.12. Mechanical features
Size EV-301-MC 323 × 301 × 85 mm (h × w × d)
Size EV-301-MC-P
444 × 301 × 85 mm (h × w × d)Size EV-301-MC-L
Size EV-601-MC
Weight (without battery)
4.40 kg (EV-301)
5.30 kg (EV-301-P)
6.60 kg (EV-601)
5.20 kg (EV-301-MC-L)
Ingress rating IP42
1
Housing metal case
Colour Pure white RAL 9010
Protection class I
(1) In mounted state
2.13. Connection and operation
Connection
see chapter 8.3: “Wiring
Diagrams” on page 20
Terminal clamps
Spring clamp type
0.5 mm² - 2.5 mm² (max.)
Switching o󰀨 the actuators in any
position
yes
1
Maximum wire length between
control unit and actuator
see “Safety instructions and
Warranty conditions”
Opening / closing process
Pole reversal of the
operating voltage
Pause time during direction change 200 ms
Maintenance
see “Safety instructions and
Warranty conditions”
(1) Only during ventilation operation
2.14. Installation and environmental requi-
rements
Ambient temperature
1
-5 to 40 °C
Storage temperature
1
-5 to 40 °C
Suitable for outdoor installation No
(1) this temperature range applies to all components of the EV-x01 system (including
battery)
2.15. Control time of the analogue and digital
inputs
Input digital (LZ, Z, A, F, A1, A2, A3) 500 ms
Input analog (B1, B2, B3) during
mains operation
500 ms
Input analog (B1, B2, B3) during
emergency power operation
2500 ms
2.16. Technical information for lead acid
batteries
Maintenance-free lead acid battery 3.2 Ah (2 needed)
Dimensions (h × w × d) 64 × 134 × 67 mm
Weight 1.10 kg
VdS registration G118039
Output voltage per battery 10.5 V DC to 14.1 V DC
Output voltage total (series connection) 21.0 V DC to 28.2 V DC
Rated capacity (total) 3.2 Ah
Life span approx. 4 years
