HOW TO CHARGE
Notice Before Charging:
I) INDEPENDENT CHARGING (AC/SOLAR CHARGING)
AC Charging
The INFINITY 2000 Expansion Battery port is located on the right side of the product. The Expansion Battery can be charged via an external
adapter and then connected to AC power.（*AC Charging: AC-DC Adapter）
AC Charging
Solar Charging
Users must follow instructions for proper machine connection. The company is not responsible for free maintenance if the machine is
damaged due to improper connection outside of the instructions during the warranty period.
You can use up to two 200W solar panels (as shown in the figure ) to charge Expansion Battery. You can use the Solar Charging Cable to
connect the Solar Connector on the solar panel and the XT60 port on the right side of the INFINITY 2000 Expansion Battery to supply power
to the INFINITY 2000 Expansion Battery.
Figure I. 200W Solar Panels x 2
