Growatt MIN 3000 TL-X User Manual

15
3.3 Size and weight
Dimensions and weight
Model
Height (H)
Width (W)
Depth (D)
Weight
MIN 2500-6000 TL-X
350mm 13.8inch
375mm 14.8inch
160mm 6.3inch
10.8kg
3.4 Storage of Inverter
If you want to storage the inverter in your warehouse, you should choose an
appropriate location to store the inverter.
 The unit must be stored in original package and desiccant must be left in the
Model Name
MIN 4200 TL-X
MIN 4600 TL-X
MIN 5000 TL-X
MIN 6000
TL-X
Max input DC voltage
550V
Max input DC current
12.5A/12.5A
Start voltage
100V
MPP voltage range
80V~550V
AC nominal voltage
230V
AC grid frequency
50/60 Hz
Max. apparent power
4200VA
4600VA
5000VA
6000 VA
AC normal output current
18.2A
20A
21.7A
26A
Power factor
0.8leading…0.8lagging
Environmental Protection
Rating
IP65
Operation Ambient
temperature
-25...+60℃ (-13...+ 140°F)
with derating above 45°C（113°F）
