Growatt MIN 3000 TL-X User Manual

33
6.8 Inverter demand response modes (DRMS)
This series inverter has the function of demand response modes, We use 8Pin socket
as inverter DRMS connection.
Information
DRMS application description
 Only applicable to AS/NZS4777.2:2015.
 DRM0, DRM5, DRM6, DRM7, DRM8 are available.
CAUTION
Damage to the inverter due to moisture and dust penetration
 Make sure the cable gland has been tightened firmly.
 If the cable gland are not mounted properly, the inverter can
be destroyed due to moisture and dust penetration. All the
warranty claim will be invalid.
6.8.1 8Pin socket pin assignment
Pin
Assignment for inverters capable
of both charging and discharging
1
DRM 5
2
DRM 6
3
DRM 7
4
DRM 8
5
RefGen
6
Com/DRM0
7
NC
8
NC
6.8.2 Method of asserting demand response modes
Mode
Socket Asserted
by shorting pins
Requirement
DRM 0
5
6
Operate the disconnection device
DRM 5
1
5
Do not generate power
DRM 6
2
5
Do not generate at more than 50% of rated power
DRM 7
3
5
Do not generate at more than 75% of rated power
AND Sink reactive power if capabie
DRM 8
4
5
Increase power generation (subject to constraints from
other active DRMs)
7 Commissioning

Growatt MIN 3000 TL-X Specifications

General

Rated Output Power	3000 W
Max. DC Power	4500 W
Max. PV Input Power	4500 W
Max. Output Power	3000 W
Nominal DC Voltage	360 V
Number of MPPT	2
Number of MPPTs	2
Max. Short Circuit Current per MPPT	15 A
Nominal AC Power	3000 W
Max. AC Power	3000 W
Nominal AC Voltage	230 V
AC Voltage Range	180-280V
Output Voltage	230 V
THDi	< 3%
DC Connection Type	MC4
Protection Degree	IP65
Operating Temperature Range	-25 °C to +60 °C
Cooling	Natural Cooling
Cooling Method	Natural Cooling
Weight	14 kg
Protection Level	IP65
Nominal Grid Frequency	50 Hz
Output Frequency	50 Hz
AC Connection Type	Plug
