Growatt MIN 3000 TL-X User Manual

45
11 Manufacturer Warranty
Please refer to the warranty card.
12 Decommissioning
12.1 Dismantling the Inverter
1 Disconnect the inverter as described in section 8 .
2 Remove all connection cables from the inverter.
CAUTION
Danger of burn injuries due to hot enclosure parts!
Wait 20 minutes before disassembling until the housing has cooled down.
3 Screw off all projecting cable glands.
4 Lift the inverter off the bracket and unscrew the bracket screws.
12.2 Packing the Inverter
If possible, always pack the inverter in its original carton and secure it with tension
belts. If it is no longer available, you can also use an equivalent carton. The box must
be capable of being closed completely and made to support both the weight and the
size of the inverter.
12.3 Storing the Inverter
Store the inverter in a dry place where ambient temperatures are always between
-25°C and +60°C.
12.4 Disposing of the Inverter
Do not dispose of faulty inverters or accessories together with household
waste. Please accordance with the disposal regulations for electronic waste
which apply at the installation site at that time. Ensure that the old unit and,
where applicable, any accessories are disposed of in a proper manner

Growatt MIN 3000 TL-X Specifications

General

Rated Output Power	3000 W
Max. DC Power	4500 W
Max. PV Input Power	4500 W
Max. Output Power	3000 W
Nominal DC Voltage	360 V
Number of MPPT	2
Number of MPPTs	2
Max. Short Circuit Current per MPPT	15 A
Nominal AC Power	3000 W
Max. AC Power	3000 W
Nominal AC Voltage	230 V
AC Voltage Range	180-280V
Output Voltage	230 V
THDi	< 3%
DC Connection Type	MC4
Protection Degree	IP65
Operating Temperature Range	-25 °C to +60 °C
Cooling	Natural Cooling
Cooling Method	Natural Cooling
Weight	14 kg
Protection Level	IP65
Nominal Grid Frequency	50 Hz
Output Frequency	50 Hz
AC Connection Type	Plug
